For production
Tech & stage plot
Everything a house engineer needs. Print this page or save it as a PDF — it is always current.
Summary
- Band Four-piece — two guitars, bass, drums, three vocals
- Inputs 8, including backing track and click
- Backline Guitar and bass amps for stage volume only; all sources reach the house via DI
Input list
| Ch | Source | Detail |
|---|---|---|
| 1 | Backing track | XLR from band interface |
| 2 | Click | XLR — IEM mix only, NOT to house LR |
| 3 | Bass DI | XLR |
| 4 | Guitar 1 pedal DI | 1/4" TRS balanced |
| 5 | Guitar 2 amp DI | XLR |
| 6 | Guitar 1 vocal | House mic |
| 7 | Guitar 2 vocal | Band mic |
| 8 | Bass vocal | Band mic |
Stage
- Drums centre-back, with the band interface beside the kit.
- Guitar 1 centre, Guitar 2 stage left, bass stage right — three vocal positions across the front.
- Guitar and bass amps are for stage volume only; everything reaches the house via DI.
Monitoring
- Click goes to in-ear monitors only and must never reach house LR.
- In the IEM mix the click is the highest priority.
- No click in any wedge or other monitor.
Questions
Anything not covered here, ask before the day.
